Description
Truck Solutions
Control and display units
for use in and on the truck body
For mobile applications, such as the visualization, operation and control of special functions in your truck, mobile work machines/construction machines and other special vehicles, it is necessary to develop and provide reliable controller and operating elements that can handle the toughest environments. Our experts are specialized in application-specific solutions for customers who attach great importance to individuality and flexibility. Besides the use of our b-plus product solutions, we extend already existing systems of our customers or develop controller according to your requirements. We also offer access to further system integrators to realize the full scope of a development from one source. We can meet the growing complexity in the commercial vehicle sector with a combination of future-oriented and technological competence as well as many years of know-how in this field.
We are happy to implement these in individual developments according to your specific requirements.
Truck Solutions
Key Features
TruckControlSwitch
With the TruckControlSwitch you can very easily realize a truck-activation over the Bodybuilder-CAN-Gateway (SAE J1939). Complex wiring belongs to the past. The system is configured for different truck – interfaces. These functions are available: Motor START / Motor STOP, Engine speed + / -, PTO active / inactive
TruckMonitorMini
TruckMonitorMini is a monitor for custom vehicle builder and body builder based on the J1939 Body Builder CAN interface or FMS interface. All common messages according to J1939 are supported. Messages sent by the truck are evaluated and shown on the interface.
TruckMonitorCabin
The TruckMonitorCabin is an additional instrument cluster for trucks. It extends a second display screen for example to the co-driver seat at driving school trucks. The provided signals from the CAN bus FleetmanagementSystem® are clearly represented on the screen.
TruckControlSwitch
Technical data
TruckControlSwitch
|
|
|---|---|
Hardware basis |
b-plus SwitchModulMaster Sealed |
Dimensions in mm |
74 x 47,4 x 44,4 |
Life time |
Up to 500.000 cycles |
Protection class |
IP68 |
Operating temperature |
-40 … +85°C |
Operating voltage |
9 – 32 V DC |
Supported truck types |
Mercedes-Benz MAN Scania Volvo Renault |
Control unit included in the cable set |
Hardware basis Micro SPS CAN 24 V – Dimensions (BxHxT): 30 x 30 x 40 mm – Protection class: IP53 – Operating temperature: -40 … +85°C – Operating voltage: 24 V DC – Standby current: < 250 µA (stand by), 30 mA (inaktiv) – Bus system: CAN-Bus (High-Speed) nach ISO 11898-2 – E1-licencse no.: 04 7362 |
TruckMonitorMini
Technical data
TruckMonitorMini
|
TruckMonitorMini XL
|
TruckMonitorMini M835
|
|
|---|---|---|---|
Hardware basis |
ifm CR0451 ifm CR9221 – clear glass |
ifm CR0452 |
DSE M835 |
Dimensions in mm |
87,5 x 87,5 x 37,7 |
109,5 x 124,5 x 40,5 |
112,5 x 115 x 49 |
Display size |
2,8″ |
4,3“ |
3,5″ |
Resolution |
320 x 240px |
480 x 272 px |
320 x 240px |
Protection class |
IP 67 (front side when installed, otherwise IP 65) |
IP 67 (front side when installed, otherwise IP 65) |
IP67 |
Qualification |
CE, e-mark |
CE, e-mark |
CE |
Operating temperature |
-30 … 80°C |
-30 .. 80°C |
-40°C .. 85°C |
Operating voltage |
8-32V DC |
8-32V DC |
8-35 V DC |
CAN protocol |
SAE J1939 – ISO 11898 – HighSpeed-CAN 5V Basic 250 kBaud |
SAE J1939 – ISO 11898 – HighSpeed-CAN / 5V Basic / 250 kBaud |
SAE J1939 – ISO 11898 – HighSpeed-CAN / 5V Basic / 250 kBaud |
Information displayed |
Page 1: Coolant temperature, fuel level Page 2: Oil pressure, oil temperature Page 3: Engine speed, Engine hours Page 4: Weight of the truck, weight of the trailer (if provided by the truck) All pages: Parking brake switch, PTO status, engine status, fuel warning |
Page 1: Coolant temperature, fuel level Page 2: Oil pressure, oil temperature Page 3: Engine speed, Engine hours Page 4: Weight of the truck, weight of the trailer (if provided by the truck) All pages: Parking brake switch, PTO status, engine status, fuel warning |
Page 1: Coolant temperature, fuel level Page 2: Oil pressure, oil temperature Page 3: Engine speed, Engine hours Page 4: Weight of the truck, weight of the trailer (if provided by the truck) All pages: Parking brake switch, PTO status, engine status, fuel warning |
Supported truck types |
Mercedes – Benz: Aufbau-CAN, Telematic-Interface; MAN: Aufbau-CAN / FMS-Interface; Scania: Ext. CAN-Bus; Volvo: BB-CAN; DAF: BB-CAN; Iveco: CAN-Bus; Renault: BB-CAN; FMS: FMS-Standard And others with standard SAE J1939 |
Mercedes – Benz: Aufbau-CAN, Telematic-Interface; MAN: Aufbau-CAN / FMS-Interface; Scania: Ext. CAN-Bus; Volvo: BB-CAN; DAF: BB-CAN; Iveco: CAN-Bus; Renault: BB-CAN; FMS: FMS-Standard And others with standard SAE J1939 |
TruckMonitorCabin
Technical data
TruckMonitorCabin 3,5″
|
TruckMonitorCabin 4,3″
|
TruckMonitorCabin 5″
|
|
|---|---|---|---|
Hardware basis |
DSE M835 |
OPUS A3 |
OPUS B3 |
Dimensions in mm |
112,5 x 115 x 49 |
142 x 98 x 47,7 |
163 x 99,7 x 32 |
Display size |
3,5″ |
4,3″ |
5″ |
Resolution |
320 x 240 px |
480 x 272 px |
800 x 480 px |
Protection class |
IP67 |
IP66 |
IP66 |
Operating temperature |
-40 … +85°C |
-30 … +65°C |
-30 … +75°C |
Power supply |
8 – 32 V DC |
9 – 36 V DC |
8 – 36 V DC |
Qualification |
CE |
CE, E-mark |
CE, E-mark |
CAN interface |
SAE J1939 – ISO 11898 – HighSpeed-CAN / 5 V Base / 250 kBaud FleetManagementSystem®-Interface |
SAE J1939 – ISO 11898 – HighSpeed-CAN / 5 V Base / 250 kBaud FleetManagementSystem®-Interface |
SAE J1939 – ISO 11898 – HighSpeed-CAN / 5 V Base / 250 kBaud FleetManagementSystem®-Interface |
Standard signals (CAN) |
Vehicle speed Engine speed Parkingbrake |
Vehicle speed Engine speed Parkingbrake |
Vehicle speed Engine speed Parkingbrake |
Customer spec. (CAN) |
Throttle, current gear, e.g. |
Throttle, current gear, e.g. |
Throttle, current gear, e.g. |
Additional signals (IO) |
Inputs directly on the display: Flasher left Flasher right Main beam |
Inputs with extension module (CAN automotive relais): Flasher left Flasher right Main beam |
Inputs with extension module (CAN automotive relais): Flasher left Flasher right Main beam |
Supported truck FleetmanagementSystem interfaces: |
Daimler MAN Scania Iveco Volvo DAF Renault |
Daimler MAN Scania Iveco Volvo DAF Renault |
Complete your setup
Order information
Order information TruckControlSwitch
| Name | Order number | Description |
| SwitchModulMaster Sealed – TruckControlSwitch | B12460-SMM-002-E333 | SwitchModul Master Sealed for the connection to CAN (J1939) with LIN for the SwitchModulExpansion, IP68, 500.000 Cycles, – 40..+85°C, 9 .. 32 V DC, complete unit with layout TruckControlSwitch |
| KeypadModulSupply | B12504-KMS-100-2000 | Cable set power supply and CAN-Bus for KeypadModulMaster and SwitchModulMaster Sealed, Length: 2 m |
| Micro SPS CAN 24 V incl. TCS-Software | 1.107.210.00_TCS | Micro SPS CAN 24 V incl. TruckControlSwitch – Software |
Order information TruckMonitorMini
| Name | Order number | Description |
| TruckMonitorMini | B12100-TMM-001-0451 | |
| TruckMonitorMini (clear glass) | B12100-TMM-001-9221 | |
| Connection | B12090-CPS-002-0500 | CANPowerSupply M12 Cable socket tilted 5m 4pole CAN-Cord with 120 Ohm Resistor (other lengths available) |
| Mounting frame | 4000333 | Mounting frame for flat front panel mounting (EC0403) |
| RAM Mounting | 4000334 | RAM-Mount Set 1“ (EC0405) |
| Name | Order number | Description |
| TruckMonitorMini XL | B12100-TMM-001-0452 | |
| Connection | B12090-CPS-002-0500 | CANPowerSupply M12 Cable socket tilted 5m 4pole CAN-Cord with 120 Ohm Resistor (other lengths available) |
| Mounting frame | 4000333 | Mounting frame for flat front panel mounting (EC0403) |
| RAM Mounting | 4001979 | RAM-Mount Set 1“ (EC0406) |
| Name | Order number | Description |
| TruckMonitorMini M835 | B12100-TMM-001-M835 | |
| Connection | 4001954 | Socket incl. pins DEUTSCH DT16-A, 18pin |
| RAM Mounting | 4001951 | RAM Mount + Adapter cover M835 |
Order information TruckMonitorCabin
| Name | Order number | Description |
| TruckMonitorCabin 3,5″ | B12100-TMC-035-0001 | TruckMonitorCabin – DSE835, 3,5” display |
| TruckMonitorCabin 4,3″ | B12100-TMC-043-0001 | TruckMonitorCabin – OPUS A3, 4,3” display |
| TruckMonitorCabin 5″ | B12100-TMC-050-0001 | TruckMonitorCabin – OPUS B3, 5” display |
